GIGABYTE
Gigabyte B700H 80 Plus Bronze SemiModular
₹4,773.65
In Stock
Product Attributes
| Smps Wattage Id | 11 |
| Smps Type Id | 1 |
| Color Id | 4 |
| Smps Modular | semi_modular |
| Brand | GIGABYTE |
Description
FEATURES
Modular Design
High quality Japanese electrolytic capacitors
120mm smart control fan
80 Plus Bronze certified
Single +12V rail
Supports NVIDIA SLI / AMD CROSSFIRE
Modular Design
The black flat cables are modular. Installing only the cables you need to increase the airflow and to improve the chassis thermal performance.
High Quality Japanese Electrolytic Capacitors
Main electrolytic capacitors are high quality Japanese electrolytic capacitors, to produce the efficient performance and to ensure the longer reliability.
Technical Specifications
| Model | B700H |
| Type | Intel Form Factor ATX 12V v2.31 |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240 Vac (full range) |
| Input Current | 10A |
| Input Frequency | 47-63 Hz |
| Output Capacity | 700W |
| Dimension | D140 x W150 x H86mm |
| Fan Type | 120mm Double ball bearing fan |
| Efficiency | 85% at typical load |
| MTBF | >100,000 hours |
| Protection | OVP/OPP/SCP/UVP |
| Regulatory | CE/BSMI/EAC/TUV/FCC/UL/RCM/KCC/CCC |
| Connectors | MB 20+4 Pin x1 CPU 4+4 Pin x1 PCI-e 6+2 Pin x4 SATA x7 4Pin Peripheral x3 4Pin Floppy x1 |
| Cable Type | Black Flat Cables |
| Warranty | 5 Years |
