DEEPCOOL
DEEPCOOL PQ1000M 80 PLUS GOLD
₹13,423.95
In Stock
Product Attributes
| Smps Wattage Id | 5 |
| Smps Type Id | 2 |
| Color Id | 4 |
| Smps Modular | fully_modular |
| Brand | DEEPCOOL |
Description
PQ1000MIntroducing a new generation of power reliability, the DeepCool PQ-M Series 80 PLUS Gold Modular Power Supply delivers high efficiency and stability for performance PC systems needing ultra-quiet operation with silent fan modes.
Technical Specifications
| Type | ATX12V V2.4 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| 80PLUS Certifications | GOLD |
| Fan Size | 120mm |
| Fan Bearing | FDB |
| Topology | Active PFC + Full Bridge SRC LLC + DC to DC |
| Capacitors | Full Japan Electrolytic Capacitors |
| Power Good Signal | 100-500ms |
| Hold Up Time | ≥16ms (80% load)) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP |
| Operation Temperature | 0 - 40 °C |
| Regulatory | CCC/CE/FCC/TUV-SUD/cTUVus/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA/BIS/KC |
| Erp Regulation | ErP 2013 |
| MTBF | 100,000 Hours |
| Warranty | 10 Years |
| EAN P/N | 6933412702009 R-PQA00M-FA0B-CN 6933412702016 R-PQA00M-FA0B-AU 6933412702023 R-PQA00M-FA0B-EU 6933412702030 R-PQA00M-FA0B-JP 6933412702047 R-PQA00M-FA0B-UK 6933412702054 R-PQA00M-FA0B-US 6933412702061 R-PQA00M-FA0B-AR 6933412702078 R-PQA00M-FA0B-BR 6933412702085 R-PQA00M-FA0B-WO 6933412702092 R-PQA00M-FA0B-BP |
