Antec
Antec HCG 750 80 Plus Bronze Fully Modular
₹8,342.10
In Stock
Product Attributes
| Smps Wattage Id | 3 |
| Smps Type Id | 1 |
| Color Id | 4 |
| Smps Modular | fully_modular |
| Brand | Antec |
Description
Dimension: 165(L)*150(W)*86(H)
Guaranteed 750W Continuous Power from Antec
100% Modular－Improves airflow and reduces clutter
DC-DC-Based on a DC-DC topology
80 PLUS® Bronze certified－Up to 89% efficient, to reduce your electricity bill
Antec Quality 5-year warranty and lifetime global 24/7 support
135mm DBB Fan－Whisper-quiet high-quality double ball bearing fan with long lifetime
99%+12V - Output for maximum CPU &s; GPU support
CircuitShield™－Full suite of industrial grade protections: OCP, OVP, SCP, OPP, OTP, SIP, NLO
100% Japanese capacitors achieve unprecedented tight voltage regulation &s; low ripple &s; noise to maximize your system’s performance
28(18+10) pin MBU socket - For possible future MBU connectors
ATX12V 2.4－Engineered according to the newest PSU guideline and compatible with the latest CPU generation
Technical Specifications
| Model | HCG750 Bronze |
| Type | ATX 12V 2.4 |
| Modular | Fully Modular |
| Dimension (W x L x H) | 165(L)*150(W)*86(H) |
| Warranty | 5 years |
| Input Voltage | 100-240 VAC ±10% |
| Input Current | 12A-6A |
| Input Frequency Range | 50Hz-60Hz |
| PFC | Active PFC (>0.9 typical) |
| Power Good Signal | 100-500ms |
| Efficiency | 89% Typically |
| Protection | OCP/OVP/SCP/OPP/OTP/SIP/NLO |
| Output Capacity | 750W |
| Operation Temperature | 0~40°C |
| Regulatory | cTUVus/TUV/CB/RCM/CE/EAC/FCC |
| Fan | 135mm DBB Fan |
| Certifications | 80 Plus Bronze |
| Connector pin | 1 x MB 24(20+4) Pin |
| Connector eps | 2 x 8(4+4) Pin EPS 12V |
| Connector pci | 4 x 8(6+2) Pin PCI-E |
| Connector sata | 9 x SATA |
| Connector molex | 4 x Molex |
| Connector fdd | 1 x FDD |
| Net Weight | 1.62 kgs |
| Gross Weight | 2.78 kgs |
| UPC# | 0-761345-11540-7 HCG750 Bronze 0-761345-11542-1 HCG750 Bronze AU 0-761345-11541-4 HCG750 Bronze CN 0-761345-11543-8 HCG750 Bronze EC 0-761345-11544-5 HCG750 Bronze GB 0-761345-11545-2 HCG750 Bronze JP |
