| Smps Wattage Id | 3 |
| Smps Type Id | 2 |
| Color Id | 4 |
| Smps Modular | fully_modular |
| Brand | Lian Li |
| MODEL | SP750 BLACK / SP750 WHITE |
| Dimensions | (D)100 mm X (W)63.5mm X (H)125 mm |
| Power supply design | Fully modular |
| Color | Black / White |
| Material | Steel/brushed aluminum housing |
| Form factor | SFX |
| Certification | 80 PLUS Gold |
| Max. DC Output | 750W |
| Combined +3.3V & +5V | 100W |
| Combined +12V | 744W |
| Input Voltage | 100 – 240 Vrms |
| Input Frequency Range | 50Hz – 60 Hz |
| PFC | Active PFC (PF)>0.90 at full load |
| Efficiency | 91.89% Max |
| Protective Circuit | OCP/ OPP/ UVP/ OVP/ OTP/ SCP |
| Connectors | 1 x 24 / 20-Pin motherboard connector (300mm) x 1pcs 2 x 8 / 4-Pin CPU / ATX 12V connector (450mm-70mm) x 1 pcs 1 x 8 / 6+2 Pin PCIe connector (400mm) x 1pcs 2 x 8 / 6+2 Pin PCIe connector (400mm-120mm) x 1pcs 4 x SATA connector (120mm-120mm-120mm-120mm) x 2pcs 4 x 4-Pin Peripheral connector (120mm-120mm-120mm-120mm) x 1pcs |
| 750W FAN RPM | 1000-2800 RPM |
| Noise Level | 17.1-43.1 DBA |
| Bearing Type | 31.Fluid Dynamic Bearing (FDB) |
| Warranty | 5 years |
