| Brand |
BenQ |
| Model |
SW242Q |
| Screen Size |
24.1 inch |
| Panel Type |
IPS |
| Backlight Technology |
LED backlight |
| Resolution (max.) |
2560x1600 |
| Brightness (typ.) |
400 nits |
| HDR |
HDR10 |
| Viewing Angle (L/R) (CR>=10) |
178°/178° |
| Response Times (GtG) |
5 ms |
| Native Contrast |
1000:01:00 |
| Refresh Rate (Hz) |
60 |
| Color Gamut |
100% sRGB, 98% P3, 99% Adobe RGB |
| Color Mode |
Adobe RGB, B+W, Calibration 1, Calibration 2, Calibration 3, Custom, DCI-P3, DICOM, Display P3, HDR, M-Book, Paper Color Sync, Rec.709, sRGB |
| Aspect Ratio |
0.673611111 |
| Display Colors |
1.07 billion colors |
| PPI |
125 |
| Display Screen Coating |
Fine Coated Panel |
| Color Temperature |
5000K, 6500K, 9300K, User-K, User-RGB |
| Gamma |
1.6 - 2.6, sRGB |
| HDCP |
2.2 |
| OSD Language |
Arabic, Chinese (simplified), Chinese (traditional), Czech, Deutsch, English, French, Hungarian, Italian, Japanese, Korean, Netherlands, Polish, Portuguese, Romanian, Russian, Spanish, Swedish |
| AMA |
YES |
| Headphone Jack |
Yes |
| Voltage Rating |
100 - 240V |
| Power Supply |
Built-in |
| Power Consumption (normal) |
27 W |
| Power Consumption (max) |
170 W |
| Power Consumption (sleep mode) |
0.3 W |
| Power Delivery(USB C / Thunderbolt 3) |
90W W |
| Tilt (down/up) |
-5˚ - 20˚ |
| Swivel (left/right) |
30˚/30˚ |
| Pivot |
90˚ |
| Height Adjustment Stand |
120mm mm |
| Dimensions (HxWxD) (mm) |
452.59-572.59 x 533.2 x 262.6 |
| Dimensions (HxWxD) (inch) |
17.8-22.5 x 21 x 10.3 |
| Dimensions (HxWxD) (w/o Base) (with shading hood) (mm) |
539.8 x 364.4 x 219.1 |
| Dimensions (HxWxD) (w/o Base) (with shading hood) (inch) |
539.8 x 364.4 x 219.1 |
| Dimensions(HxWxD) (with shading hood) (mm) |
460.69-580.49 x 539.8 x 311.4 |
| Dimensions(HxWxD) (with shading hood) (inch) |
18.1-22.9 x 21.2 x 12.2 |
| Net Weight (kg) |
7.8 |
| Net Weight (lb) |
17.2 |
| Net Weight (w/o Base) (kg) |
6.1 |
| Net Weight (w/o Base) (lb) |
13.4 |
| Net Weight (with shading hood) (kg) |
8.61 |
| VESA Wall Mount |
100x100 mm |
| Net Weight (with shading hood) (lb) |
19 |
| Other Accessories |
Calibration Report, IO Cover, QSG, Safety Instruction |
| Card Reader |
SD/SDHC/SDXC/MMC |
| HDMI (v2.0) |
2 |
| DisplayPort (v1.4) |
1 |
| USB C(PowerDelivery 90W, DisplayPort Alt Mode, Data) |
1 |
| USB Type B ( Upstream ) |
1 |
| USB 3.1 ( Downstream ) |
2 |
| All-in-One Connection |
USB-C |
| TUV Certificate |
Anti-Reflection |
| calman verified |
Yes |
| Pantone Validated |
Yes |
| Pantone SkinTone™ Validated |
Yes |
| Video Format Support |
Yes |
| Factory Calibration Report |
Yes |
| 3D-LUT |
16bit |
| Delta E(avg) |
≤1.5 |
| Gamut Duo |
Yes |
| Black & White mode |
Yes |
| KVM Switch |
Yes |
| Black Level |
Yes |
| Auto Pivot |
Yes |
| Hardware Calibration |
Yes |
| Uniformity Technology |
Yes |
| Palette Master Ultimate |
Yes |
| Paper Color Sync |
Yes |
| LightSpace Ready |
Yes |
| calman ready |
Yes |
