| Screen Size |
25 |
| Panel Type |
IPS |
| Backlight Technology |
LED backlight |
| Resolution (max.) |
2560x1440 |
| Brightness |
350 cd/㎡ |
| Native Contrast(typ.) |
1000:01:00 |
| Viewing Angle (L/R;U/D) (CR>=10) |
178/178 |
| Response Time |
4ms (GtG) |
| Refresh Rate |
60Hz |
| Aspect Ratio |
16:09 |
| Display Colors |
16.7 million colors |
| Color Gamut |
100% sRGB/Rec. 709 |
| Display Area(mm) |
552.96(H) x 311.04(V) |
| Pixel Pitch (mm) |
0.216 |
| PPI |
117 |
| DCR (Dynamic Contrast Ratio) (typ.) |
20M:1 |
| Built-in Speaker |
2Wx2 |
| Headphone Jack |
Yes |
| Product Color |
Gray |
| Picture Mode |
Rec.709 / sRGB / CAD/CAM / Animation / Standard / Low Blue Light / Dark Room / M-Book / User |
| Gamma |
1.8 - 2.6 |
| OSD Language |
18 Languages - English, French, Deutsch, Italiano, Spanish, Polish, Czech,
Hungarian, Korean, Romanian, Dutch, Russian, Swedish, Portuguese, Japanese,
Chinese (traditional), Chinese (simplified), Arabic |
| HDCP |
1.4 |
| VESA Wall Mount |
Yes |
| AMA |
Yes |
| Display Screen Coating |
Anti-Glare |
| Flicker-Free Technology |
Yes |
| Low Blue Light |
Yes |
| Brightness Intelligence (B.I.) |
Yes |
| Delta E |
≦ 3 (average) |
| Animation mode |
Yes |
| CAD/CAM mode |
Yes |
| ECO sensor |
Yes |
| Darkroom mode |
Yes |
| Auto Pivot |
Yes |
| Factory Calibration Report |
Yes |
| HDMI |
HDMI (v1.4)x1 |
| DisplayPort |
DisplayPort (v1.2) x1 |
| Mini DisplayPort |
MiniDisplayPort (ver1.2)x1 |
| DP out |
DP out(MST) |
| USB 3.1 Hub |
USB Upstream x 1 |
| Voltage Rating |
100 - 240V |
| Power Supply |
Built-in |
| Power Consumption (on mode.) |
62W |
| Power Consumption (based on Energy Star) |
21W |
| Power Consumption (stand by mode) |
0.5W |
| Power Consumption (sleep mode) |
0.5W |
| AC Switch |
Yes |
| Dimensions (HxWxD mm) (w/o Base) |
359.51 x 570.2 x 58.79 |
| Dimensions (HxWxD mm) |
H: 532 x 570.2 x 239.65
L: 402 x 570.2 x 239.65 |
| CTN Dimensions (HxWxD mm) |
639 x 170 x 590 |
| Net Weight (kg) (without stand) |
4.43kg |
| Net Weight (kg) |
7.2kg |
| Gross Weight (kg) |
9.2kg |
| Tilt (down/up) |
-5˚ - 20˚ |
| Swivel (left/right) |
45˚/45˚ |
| Pivot |
90˚ |
| Height Adjustment (mm) |
130 |
| Display Pilot |
Yes |
| Mac Compatible |
Yes |
| Windows® Compatible |
Windows®10, Windows®8.1, Windows®8, Windows®7 |
| Solidworks |
Yes |
| Calman Verified |
Yes |
| Pantone Validated |
Yes |
| Warranty |
3 Years |
